Specification Parameter:
-
Process
-
12nm
-
CPU
-
Quad-Core ARM Cortex-A55 64-bit processor@max 2.0 GHz
-
GPU
-
ARM Mali-G31 MP2, Supports OpenGL ES3.2, Vulkan 1.1 and OpenCL 2.0
-
Memory
-
32-bit DDR3/3L/4,LPDDR3/4
-
Storage
-
eMMC 5.0, NAND Flash, SPI NOR/NAND, SD
-
Video Processing
-
4K@75fps 10bit: AV1/H.265/VP9 P-2/AVS2, 4K@30fps: H.264 decoding
1080@60fps H.265, 1080@30fps H.264 encoding
-
HDR
-
HDR10/10+, HLG, Dolby Vision, TCH PRIME
-
Ethernet
-
10/100/1000MAC + 10/100 PHY
-
USB/PCI-e
-
1x USB2(OTG) + 1x USB3 or 2x USB2(OTG,HOST) + 1x PCIe-2
-
Audio Interface
-
Stereo DACs, SPDIF-in & out, 8Ch PDM, 12+Ch I2S in, 12+ch I2S out
-
Voice & Audio Processing
-
VAD, ASRC/EQ/DRC, eARC, HiFi4 DSP
-
Video Output
-
4K@60fps HDMI 2.1, CVBS
-
DVB
-
4xTS in, ISO7816
-
